Which two actions are performed by the Weighted Random Early Detection mechanism? (Choose two)
Correct Answer: A,D
Weighted Random Early Detection (WRED) is just a congestion avoidance mechanism. WRED drops packets selectively based on IP precedence. Edge routers assign IP precedences to packets as they enter the network. When a packet arrives, the following events occur: 1. The average queue size is calculated.2. If the average is less than the minimum queue threshold, the arriving packet is queued.3. If the average is between the minimum queue threshold for that type of traffic and the maximum threshold for the interface, the packet is either dropped or queued, depending on the packet drop probability for that type of traffic.4. If the average queue size is greater than the maximum threshold, the packet is dropped. WRED reduces the chances of tail drop (when the queue is full, the packet is dropped) by selectively dropping packets when the output interface begins to show signs of congestion (thus it can mitigate congestion by preventing the queue from filling up). By dropping some packets early rather than waiting until the queue is full, WRED avoids dropping large numbers of packets at once and minimizes the chances of global synchronization. Thus, WRED allows the transmission line to be usedfully at all times. WRED generally drops packets selectively based on IP precedence. Packets with a higher IP precedence are less likely to be dropped than packets with a lower precedence. Thus, the higher the priority of a packet, the higher the probability that the packet will be delivered
Question 98
DRAG DROP
Correct Answer:
Question 99
What is the purpose of a southbound API in a control based networking architecture?
Correct Answer: B
https://www.ciscopress.com/articles/article.asp?p=2995354&seqNum=2#:~:text=The%20Southbound%20Interface,communicate%20to%20the%20networking%20devices.&text=The%20overall%20goal%20is%20network,from%20being%20only%20a%20protocol. The Southbound Interface In a controller-based network architecture, the controller needs to communicate to the networking devices.
Question 100
Which two statements are true about the command ip route 172.16.3.0 255.255.255.0 192.168.2.4? (Choose two.)
