Refer to the exhibit, which shows partial outputs from two routing debug commands.

Which change must an administrator make on FortiGate to route web traffic from internal users to the internet, using ECMP?

• A.Set the priority of the static default route using port1 to 10. Most Voted
• B.Set the priority of the static default route using port2 to 1.
• C.Set preserve-session-route to enable.
• D.Set snat-route-change to enable.

Comment: *

Name: *

Email: *

Verification: *

Which statement about the designated router (DR) and backup designated router (BDR) in an OSPF multi-access network is true?

• A.BDR is responsible for forwarding link state information from one router to another.
• B.FortiGate first checks the OSPF ID to elect a DR.
• C.Only the DR receives link state information from non-DR routers.
• D.Non-DR and non-BDR routers will form full adjacencies to DR and BDR only.

Comment: *

Name: *

Email: *

Verification: *

View the following FortiGate configuration.

All traffic to the Internet currently egresses from port1.
The exhibit shows partial session information for Internet traffic from a user on the internal network:

If the priority on route ID 1 were changed from 5 to 20, what would happen to traffic matching that user's session?

• A.The session would be deleted, so the client would need to start a new session.
• B.The session would remain in the session table, and its traffic would start to egress from port2.
• C.The session would remain in the session table, and its traffic would still egress from port1.
• D.The session would remain in the session table, but its traffic would now egress from both port1 and port2.

Comment: *

Name: *

Email: *

Verification: *

View the exhibit, which contains a partial routing table, and then answer the question below.

Assuming all the appropriate firewall policies are configured, which of the following pings will FortiGate route? (Choose two.)

• A.Source IP address 10.72.3.27, Destination IP address 10.1.0.52.
• B.Source IP address 10.72.3.52, Destination IP address 10.1.0.254.
• C.Source IP address 10.1.0.24, Destination IP address 10.72.3.20.
• D.Source IP address 10.73.9.10, Destination IP address 10.72.3.15.

Comment: *

Name: *

Email: *

Verification: *

Examine the following partial output from two system debug commands; then answer the question below.

Which of the following statements are true regarding the above outputs? (Choose two.)

• A.Kernel indirectly accesses the low memory (LowTotal) through memory paging
• B.The unit is in kernel conserve mode
• C.The unit is running a 32-bit FortiOS
• D.The Cached value is always the Active value plus the Inactive value
