An AOS-CX switch is configured to implement downloadable user roles Examine the AOS-CX switch output:
Access11config i$ show aaa authentication port-access interface ail client-status Port Access Client Status Details

Based on this output what is the state of the users access'?

• A.No downloadable user role exists
• B.The RADIUS request timed out to the AAA server
• C.The port should be configured for 802 1X
• D.MAC authentication has passed, but 802 1X authentication is in progress

Comment: *

Name: *

Email: *

Verification: *

What is correct regarding the operation of VSX and multicasting with PIM-SM routing configured?

• A.Each VSX peers runs PIM and builds its own group database One of the VSX peers is elected as the designated router (DR) to forward multicast streams to a receiver VLAN
• B.Each VSX peers runs PIM and creates a shared group database. One of the VSX peers is elected as the designated router (DR) to forward multicast streams to a receiver VLAN.
• C.Each VSX peers runs PIM and creates a shared group database. Both VSX peers can forward multicast streams to receivers in a VLAN, achieving load sharing.
• D.Each VSX peers runs PIM and builds its own group database Both VSX peers can forward multicast streams to receivers in a VLAN achieving load sharing.

Comment: *

Name: *

Email: *

Verification: *

An administrator of a company has concerns about upgrading the access layer switches. The users rely heavily on wireless and VoIP telephony. Which is the best recommendation to ensure a short downtime for the users during upgrading the access layer switches?

• A.Install AOS-CX 6300 or 6400 switches with always-on POE
• B.Install the in-service software upgrade (ISSU) feature with clustering enabled
• C.Implement VSX on the AOS-CX access switches
• D.Implement VSF on the AOS-CX access switches

Comment: *

Name: *

Email: *

Verification: *

Examine the following AOS-CX switch configuration:

Which statement correctly describes what is allowed for traffic entering interface 1/1/3?

• A.Traffic from 10.0.12.0/24 will generate a log record when accessing 10.0.11.0/24
• B.IP traffic from 10.1.11.0/24 is allowed to access 10.1.110.0/24
• C.IP traffic from 10.0.11.0/24 is allowed to access 10.1.12.0/24
• D.IP traffic from 10.1.12.0/24 is allowed to access 172.0.1.0/23

Comment: *

Name: *

Email: *

Verification: *

An administrator is implementing a multicast solution in a multi-VLAN network. Which statement is true about the configuration of the switches in the network?

• A.IGMP must be enabled on all routed interfaces where multicast traffic will traverse
• B.IGMP requires join and leave messages to graft and prune multicast streams between switches
• C.IGMP snooping must be enabled on all interfaces on a switch to intelligently forward traffic
• D.IGMP must be enabled on all interfaces where multicast sources and receivers are connected
