The two data centers shown in the exhibit need to be connected using EVPN. Which two statements are correct in this situation? (Choose two.)

• A.Hosts in VLAN 10 can communicate with hosts in Data Center 2 using Layer 3.
• B.Hosts in VLAN 202 can communicate using Layer 3 between data centers.
• C.Hosts in VLAN 202 can communicate using Layer 2 between data centers.
• D.Hosts in VLAN 10 can communicate with hosts in Data Center 2 using Layer 2.

Comment: *

Name: *

Email: *

Verification: *

You are designing an EBGP IP fabric for a multi-side data center.
In this scenario, which two statements are true? (Choose two.)

• A.Private AS numbers can be used.
• B.Public AS numbers must be used
• C.Different AS numbers should be used on all devices.
• D.The same AS number should be used on all devices across all data centers.

Comment: *

Name: *

Email: *

Verification: *

You are designing a Layer 3 fabric underlay using EBGP. You will implement an E VPN-signaled VXLAN overlay on the Layer 3 fabric.
In this scenario, what must you do in the underlay to ensure that the VXLAN overlay will be able to function properly?

• A.Each device in the underlay should advertise its loopback address
• B.The underlay should advertise the host connected interlaces on all leaf device
• C.The underlay should support the PIM protocol
• D.The underlay should be configured with a separate VRF tor each potential tenant

Comment: *

Name: *

Email: *

Verification: *

You are considering deploying a MAC-VRF type routing instance with a VLAN-bundle service type. In this scenario, which two statements are correct? (Choose two.)

• A.It can be implemented in an ERB architecture.
• B.Multiple VLAN IDs per EVI are supported.
• C.It can be implemented in a bridge overlay architecture.
• D.VLAN normalization is supported.
