A router running EIGRP has learned the same route from two different paths Which parameter does the router use to select the best path?

• A.metric
• B.as-path
  If a router learns two different paths for the same network from the same routing protocol, it has to decide which route is better and will be placed in the routing table. Metric is the measure used to decide which route is better (lower number is better). Each routing protocol uses its own metric. For example, RIP uses hop counts as a metric, while OSPF uses cost.
  https://study-ccna.com/administrative-distance-metric/
• C.cost
• D.adminstrative distance

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

Routers R1 and R3 have the default configuration The router R2 priority is set to 99 Which commands on R3 configure it as the DR in the 10.0 4.0/24 network?

• A.R3(config)#interface Gig0/1 R3(config-if)#ip ospf priority 0
• B.R3(config)#interface Gig0/0 R3(config-if)i=ip ospf priority 1
• C.R3(config)#interface Gig0/0 R3(config-if)#ip ospf priority 100
• D.R3(config)#interface Gig0/1 R3(config-if)#ip ospf priority 100

Comment: *

Name: *

Email: *

Verification: *

When deploying syslog, which severity level logs informational messages?

• A.0
• B.2
• C.4
• D.6

Comment: *

Name: *

Email: *

Verification: *

A network engineer must back up 20 network router configurations globally within a customer environment.
Which protocol allows the engineer to perform this function using the Cisco IOS MIB?

• A.SNMP
• B.SMTP
• C.ARP
• D.CDP

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit. With which metric was the route to host 172.16.0.202 learned?

• A.38443
• B.0
• C.3184439
• D.110
