What are the benefits of a 3-Tier design over a 2-Tier? (Choose two.)

• A.Gaining the flexibility to connect the Data-Center to any Access layer switch.
• B.Offloading processing from the Core without routing at the Access layer.
• C.Lowering the cost of a deployment due to needing less switches overall.
• D.Can use lower speed links between Core to Aggregation and Aggregation to Access given the use of an Aggregation layer.
• E.Better scalability in a campus with a large number of buildings.

Comment: *

Name: *

Email: *

Verification: *

What is the correct description of a Multi-Layer Switch?

• A.has all the functionality of a Layer 2 switch and most of the functionality of a Layer 3 router
• B.any switch that supports PoE, LLDP-MED and Flow Control
• C.a switch with Layer 3 routing capabilities but lacks any Layer 1 features as a consequence
• D.multi-Layer refers specifically to using chassis switches with several line cards over stack port switches

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

Switch-1 is not the root bridge. The ports shown are all the connected pointtopoint interfaces. What Role (hidden by the blue rectangle) will be assigned to the Lag 1 interface?

• A.Root
• B.Backup
• C.Designated
• D.Alternate

Comment: *

Name: *

Email: *

Verification: *

Refer to the exhibit.

Traffic is failing between Core-1 and Host-B. IP addressing has correctly been applied, and all interfaces are attached to the vrf GREEN.
Which configuration will correct the issue?

• A.Host-B: assign the default-gateway address 10.1.20.181
• B.Core-1(config)# ip route 10.1.20.0/24 10.1.1.2 vrf GREEN Host-B: assign the default-gateway address 10.1.20.181
• C.Core-1(config)# ip route 10.1.20.0/24 10.1.1.2 vrf GREEN Host-B: assign the default-gateway address 10.1.20.1
• D.Core-2(config)# ip route 0.0.0.0/0 10.1.1.1 vrf GREEN Host-B: assign the default-gateway address 10.1.20.181

Comment: *

Name: *

Email: *

Verification: *

Match each description to the correct management tool for Aruba AOS-CX.

Correct Answer:
