What is the effect of an iRule error such as referencing an undefined variable?

• A.The execution of the current event within the iRule will be terminated.
• B.The iRule execution will continue with the next statement.
• C.The connection will continue, but the iRule will NOT be executed again for the lifetime of the connection.
• D.The iRule execution will be terminated, and both the client and server side connections will be reset.

Comment: *

Name: *

Email: *

Verification: *

An application is configured on an LTM device:
Virtual server: 10.0.0.1:80 (VLAN vlan301)
SNAT IP: 10.0.0.1
Pool members: 10.0.1.1:8080, 10.0.1.2:8080, 10.0.1.3:8080 (VLAN vlan302)
Which packet capture should the LTM Specialist perform on the LTM device command line interface to capture only client traffic specifically for this virtual server?

• A.tcpdump -ni vlan301 -s 0 'port 80 and host 10.0.0.1' -w /var/tmp/trace.cap
• B.tcpdump -ni vlan301 -s 0 'port 8080 and host 10.0.1.1 or host 10.0.1.2 or host 10.0.1.3' w /var/tmp/trace.cap
• C.tcpdump -ni 0.0:nnn -s 0 'host 10.0.0.1' -w /var/tmp/trace.cap
• D.tcpdump -ni vlan302 -s 0 'port 8080 and host 10.0.1.1 or host 10.0.1.2 or host 10.0.1.3' w /var/tmp/trace.cap
• E.tcpdump -ni 0.0:nnn -s 0 '(port 80 and host 10.0.0.1) or (port 8080 and host 10.0.1.1 or host 10.0.1.2 or host 10.0.1.3)' -w /var/tmp/trace.cap

Comment: *

Name: *

Email: *

Verification: *

A device group is made up of four members: LTM-A, LTM-B, LTM-C, and LTM-D. An LTM Specialist makes a configuration change on LTM-B. Later, a different LTM Specialist notices a "changes pending" message on all devices. When logged into LTM-D, the LTM Specialist attempts to config-sync to the device group. The sync operation fails.
Why is the LTM Specialist on LTM-D unable to synchronize the configuration to the group?

• A.The changes made on LTM-B are invalid.
• B.LTM-B is the device eligible to initiate a config-sync.
• C.LTM-D has the lowest commit-id of the group.
• D.NTP is NOT configured on the devices in the group.

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit-

-- Exhibit -Refer to the exhibit. A layer 2 nPath routing configuration has been deployed. A packet capture contains a client
connection packet with the following properties:
Source IP: <Virtual Server>
Destination IP: <Client A>
At which two locations could the packet capture have been taken? (Choose two.)

• A.the internal interface of the Internet firewall
• B.the network interface of web server
• C.the DMZ interface of the Internet firewall
• D.the external VLAN interface of the LTM device

Comment: *

Name: *

Email: *

Verification: *

-- Exhibit - -- Exhibit -

Refer to the exhibits.
Which two servers are missing two frequently used URLs? (Choose two.)

• A.172.16.20.2 /text.one /text.txt
• B.172.16.20.3 /text.one /browserspecific.html
• C.172.16.20.2 /text.one /browserspecific.html
• D.172.16.20.1 /text.txt /browserspecific.html
• E.172.16.20.1 /text.one /text.txt
